Signal Strength, Signal Quality & Interference

Start by determining whether the problem is primarily insufficient signal level or degraded signal quality.

If possible, use a professional digital TV signal meter that can separately display RF signal level and a quality measurement such as SNR or another modulation quality indicator.

Then simplify the antenna system.

Temporarily eliminate unnecessary splitters, adapters, filters, amplifiers, and long distribution paths where practical. Test the antenna through the simplest known good coaxial path to one receiver. This helps determine whether the problem originates at the antenna or somewhere within the distribution network.

Inspect the coaxial cable and connectors for loose fittings, corrosion, moisture, damaged shielding, crushed cable, poor compression connectors, or other conditions that could allow ingress or create impedance problems.

If electrical interference is suspected, turn off potential sources one at a time. LED lights, switching power supplies, chargers, motors, appliances, computers, and other electronic equipment can be investigated this way.

If multipath is suspected, experiment with antenna direction, height, and location. A directional antenna may improve reception by reducing reflected signals arriving from unwanted directions. ATSC guidance recognizes multipath handling as a significant factor in reliable digital television reception.

If only one RF channel is affected, investigate sources that could specifically interfere with that frequency, including co-channel or adjacent channel broadcasts.

Finally, do not assume that increasing signal strength is automatically the solution. A strong, distorted, noisy, or interference contaminated signal can be less reliable than a weaker but cleaner signal.

For digital television, the objective is always adequate signal level combined with adequate signal quality and SNR.

Yes. A preamplifier is useful when it is solving a signal level problem, but it cannot distinguish between every desired and undesired signal entering its passband.

The amplifier increases the level of the desired television signals, but it can also amplify noise and unwanted RF signals that reach its input.

More importantly, a sufficiently strong signal can overload the amplifier.

When an RF amplifier is driven beyond its linear operating range, it can generate distortion and intermodulation products that were not present at the antenna. Those unwanted products can fall within television channels and reduce reception quality.

This means an installation can actually show worse reception after adding an amplifier, even though the RF level is technically higher.

Strong local television stations, FM transmitters, cellular signals, and other RF sources can all contribute to the total amount of energy entering a broadband preamplifier.

Filtering can sometimes help when a known out of band source is responsible. For example, an FM filter can attenuate strong FM signals before they enter susceptible amplification or receiving equipment.

The correct amplifier should therefore be selected based on the signal levels at the antenna, distribution losses, required gain, noise performance, and RF environment rather than assuming that higher gain is always better.

Yes. Some LED lighting products and their electronic power supplies or drivers can generate radio frequency noise that interferes with television reception.

The LED itself is not necessarily the source of the problem. LED lighting commonly uses electronic driver circuitry that converts AC electrical power into the voltage and current required by the LEDs. Poorly designed, defective, or inadequately filtered switching electronics can generate broadband RF noise.

This interference can be particularly noticeable on High VHF television channels 7 through 13, which occupy 174 to 216 MHz. In a marginal VHF installation, electrical noise within or near this frequency range can reduce the effective SNR enough to cause intermittent pixelation or complete loss of reception.

If channels 7 through 13 experience unexplained intermittent pixelation, especially when lights are switched on, LED lighting should be included in the troubleshooting process.

The interfering light does not necessarily need to be immediately beside the television or antenna. RF noise can radiate through the air or travel along building wiring, and under unfavorable conditions a problematic device can affect reception at substantial distances. A fixed 150 foot interference radius should not be treated as a universal technical limit, because the actual distance depends on the noise generated by the device, wiring, antenna location, desired signal strength, building construction, and other RF conditions.

A practical troubleshooting method is to observe the affected channel while switching suspected LED lights and other electronic devices off at the circuit level. If reception immediately improves when a particular device is disconnected from power, that device or its associated power supply may be contributing interference.

Replacing the defective or poorly filtered LED lamp or driver is generally preferable to attempting to overpower the interference with additional antenna amplification.

Many different RF and electrical conditions can interfere with television reception. The most common categories include:

Multipath and reflections: Multiple delayed copies of the desired signal reach the antenna after reflecting from buildings, terrain, aircraft, or other objects.

Refraction and diffraction: Radio signals can bend or change direction as they interact with atmospheric layers, terrain, edges of structures, and other physical conditions.

Co-channel interference: Another television station uses the same RF channel and becomes strong enough at your location to interfere with the desired station.

Adjacent channel interference: A strong broadcast on an RF channel immediately next to the desired channel can challenge the receiver's ability to isolate the desired signal. ATSC receiver guidelines specifically include adjacent channel interference rejection.

Airplane or moving-object reflections: Aircraft and other moving objects can create changing reflected signal paths. ATSC technical guidance specifically identifies airplane flutter and moving objects as sources of Doppler and dynamic multipath effects.

FM interference: Strong FM radio transmissions occupy frequencies immediately above Low VHF television channel 6. Extremely strong nearby FM signals can interfere with portions of a television receiving system, particularly VHF reception or overloaded amplifiers. Channel Master offers an FM filter specifically to reject 88 to 124 MHz while passing television frequencies.

CB and amateur radio interference: Nearby radio transmitters can produce very strong RF fields. Properly functioning equipment should remain within applicable emission requirements, but sufficiently strong nearby signals, harmonics, overloaded amplifiers, poor shielding, or defective connections can allow unwanted energy to affect reception.

Electromagnetic interference, or EMI: Motors, switching power supplies, appliances, electrical equipment, chargers, computers, and other electronic devices can generate broadband or narrowband RF noise.

LTE and cellular interference: Strong cellular signals outside the current television band can overload some antenna amplifiers or receiving systems, particularly when amplification is used and the system has insufficient filtering.

Amplifier overload: A preamplifier receiving signals that are too strong can become nonlinear and create distortion or unwanted mixing products. Adding more amplifier gain can therefore make reception worse.

Ingress: Unwanted RF energy enters the coaxial distribution system through poor shielding, damaged cable, loose connectors, or other openings.

Egress: RF energy inside the coaxial system escapes through inadequate shielding or defective connections. A problem that permits egress can also indicate compromised shielding that allows ingress.

Impedance mismatches: Damaged cable, improperly installed connectors, inappropriate components, or severe impedance discontinuities can create RF reflections within the coaxial transmission line.

Identifying the type of interference is important because the correct solution depends on the cause. An amplifier cannot solve every interference problem and can make some conditions worse.

Multipath occurs when multiple versions of the same television signal reach the antenna over different physical paths.

One signal might travel relatively directly from the broadcast tower to the antenna while another reflects from a building, hill, aircraft, or other object before reaching the antenna.

Because the paths have different lengths, the signals arrive at slightly different times and with different amplitudes and phases.

Modern digital television receivers contain equalization technology designed to handle a certain amount of multipath. ATSC receiver guidelines specifically address multipath cancellation and signal recovery as part of the digital receiver front end.

However, sufficiently strong or rapidly changing multipath can exceed the receiver's ability to compensate.

A directional antenna can sometimes improve multipath conditions by favoring the desired signal path while reducing reflected signals arriving from other directions. ATSC technical guidance likewise notes that directional receiving antennas can substantially reduce multipath distortion in some environments.

This is one reason moving an antenna only a few feet, changing its height, or slightly changing its direction can sometimes produce a significant improvement even though the broadcast tower has not moved.

Because the television needs a signal that is both strong enough and clean enough to decode.

Imagine a person speaking loudly in a crowded room. Increasing the person's voice level helps only until competing voices and noise make the words difficult to distinguish. The desired voice can be strong while intelligibility remains poor.

A digital television receiver faces a similar problem.

A strong desired signal can still be impaired by:

Multipath

Co-channel interference

Adjacent channel interference

Electrical noise

Strong FM signals

LTE or other nearby RF signals

Amplifier overload

Impedance discontinuities

Poor shielding

Interference entering through damaged coaxial cable or connectors

ATSC receiver guidance specifically includes interference rejection and multipath handling because these conditions can determine whether an otherwise adequate signal can be decoded.

Once errors become greater than the receiver's demodulation and error correction systems can successfully handle, the viewer may see pixelation, frozen video, audio dropouts, or complete loss of the channel.

This is why adding amplification to an already strong but poor quality signal can fail to solve the problem.

It depends on the television. There is no universal requirement that the percentage or bar graph displayed by a consumer television represent an absolute RF signal level.

Many televisions display a manufacturer specific indication derived from information available inside the tuner or demodulator. Depending on the television, a display labeled Signal Strength may be influenced by signal level, signal quality, SNR, error rate, tuner automatic gain control, or a combination of measurements.

Therefore, a television displaying 40 percent signal does not necessarily mean that the actual RF power is 40 percent of some standardized maximum.

This becomes particularly important when troubleshooting with an amplifier.

If the television displays a low number because the underlying problem is poor signal quality, multipath, or interference, adding an amplifier may increase the RF signal level without improving the condition preventing reliable decoding.

The television's displayed number might remain unchanged or, in some situations, become worse if the additional amplification contributes to overload or increases the level of unwanted signals along with the desired signal.

A professional RF meter capable of separately measuring signal level and digital signal quality provides much more useful diagnostic information than a single percentage displayed by a television.

The television's meter is still useful for comparing changes within the same installation, but it should not automatically be interpreted as an absolute RF power measurement.

Signal strength and signal quality describe different characteristics of a received television signal, and a strong signal does not necessarily mean that the signal can be reliably decoded.

Signal strength, sometimes called signal level, describes the amount of RF power reaching the receiver. Professional RF meters commonly express signal level in units such as dBm.

Signal quality describes how usable the desired digital signal is after considering noise, interference, multipath, distortion, and other impairments.

SNR, or Signal to Noise Ratio, compares the desired signal with the noise present in the received channel. It is normally expressed in decibels. A higher SNR means there is greater separation between the desired signal and the noise floor.

For digital television, adequate signal level and adequate signal quality are both necessary. A weak but very clean signal may be decodable, while a much stronger signal contaminated by interference or severe multipath may not be.

ATSC receiver design reflects this distinction. The receiver must handle RF signal level, interference, multipath, demodulation, and forward error correction before the television can successfully recover the digital broadcast.

This is why the goal of an antenna system should not simply be to produce the strongest possible signal. The goal is to deliver adequate signal level with sufficient signal quality and operating margin for reliable decoding.
