Coaxial Cable & TV Signal Loss

No. The designation RG6 describes a general type of 75 ohm coaxial cable, but it does not mean every RG6 cable is manufactured from identical materials or provides identical electrical, shielding, environmental, or mechanical performance.

Two cables can both be sold as RG6 while differing in center conductor construction, conductor material, copper content, dielectric material, shielding design, shielding effectiveness, attenuation, jacket material, UV resistance, manufacturing tolerances, and overall durability.

These differences can affect how much RF signal is lost through the cable, how effectively the cable rejects outside interference, how much DC voltage is lost when powering equipment through the coax, and how reliably the cable performs outdoors over time.

This is why Channel Master recommends evaluating coaxial cable as an important RF component of the antenna system, rather than treating all cable labeled RG6 as interchangeable.

Channel Master's current RG6 cables use tri-shield 75 ohm construction, weather resistant compression connectors, UV resistant jackets, and an enhanced copper content center conductor designed for both television RF signals and DC power applications.

The difference is primarily the construction of the cable's center conductor.

A solid copper conductor is copper throughout its cross section.

A copper clad steel conductor, commonly called CCS, uses a steel core with copper applied around the outside.

Both designs can be used successfully for RF transmission because of the skin effect, where alternating current at radio frequencies becomes increasingly concentrated toward the outer portion of a conductor as frequency increases. This allows a properly manufactured copper clad steel center conductor to perform effectively for television RF signals.

However, DC electricity behaves differently. DC current uses the entire cross section of the conductor, so the electrical resistance of the underlying conductor material becomes much more important.

Steel has substantially higher electrical resistivity than copper. Therefore, when DC power must travel through coaxial cable to operate a mast mounted preamplifier, powered antenna, or another device, center conductor construction and resistance become particularly important.

Even among copper clad steel cables, the amount and quality of copper can differ. Channel Master's current coaxial cable uses an enhanced copper content copper clad center conductor specifically selected to provide reliable RF performance while also supporting DC power for amplifiers and powered antenna equipment. Channel Master specifies its current premade cable for DC power applications up to 24 volts over distances up to 150 feet.

The important point is that RF performance and DC power performance are not exactly the same specification. A cable that appears to carry television RF signals adequately may still have excessive resistance for a demanding DC powered application.

No. The number of shielding layers alone does not determine the overall shielding effectiveness of a coaxial cable.

Terms such as standard shield, dual shield, tri-shield, and quad-shield describe the general construction of the shielding system, but the actual performance also depends on the materials used, foil coverage, braid coverage and density, conductivity, manufacturing quality, connector compatibility, and how well the complete shielding system maintains electrical continuity.

A well engineered tri-shield cable can therefore provide better shielding effectiveness than a poorly constructed quad-shield cable.

This distinction is important because consumers sometimes assume that simply counting shielding layers provides a reliable ranking of cable quality. It does not.

Shielding effectiveness determines how well the coaxial cable prevents unwanted external RF energy from entering the signal path, which is called ingress, and how well it prevents RF energy inside the cable from escaping, which is called egress.

Channel Master uses premium tri-shield construction because the complete shielding system is designed around high shielding effectiveness rather than simply maximizing the number of layers. Channel Master's RG6 cables are designed specifically for television antenna applications and for maintaining signal integrity in indoor and outdoor installations.

For this reason, Channel Master recommends its own coaxial cable with Channel Master antenna and amplifier systems. The objective is to prevent an otherwise properly designed antenna system from being limited by an unknown or underperforming cable purchased solely because it carries an RG6 or quad-shield label.

Every coaxial cable introduces some amount of attenuation, meaning the RF signal becomes weaker as it travels through the cable.

The amount of attenuation depends primarily on the cable construction, frequency, and length.

Longer cables introduce more loss than shorter cables. Cable attenuation also generally increases with frequency, meaning a UHF television signal near the upper end of the television band will normally experience more cable loss than a lower frequency VHF signal traveling through the same length and type of cable.

Cable manufacturers commonly specify attenuation in decibels per 100 feet at several frequencies.

The losses are cumulative. If a cable introduces 5 dB of attenuation and a splitter later introduces another 4 dB of insertion loss, approximately 9 dB has been removed from the original signal level before accounting for any other components.

Cable loss does not necessarily cause reception problems when signals are strong enough to tolerate it. Problems occur when attenuation reduces a desired channel until there is insufficient signal margin for the tuner to decode it reliably.

This is why cable length and quality become increasingly important in weak signal installations and systems distributing signals over long distances.

Yes. This is an important distinction because the coaxial cable can simultaneously carry RF television signals in one direction and DC electrical power in the other direction.

A mast mounted preamplifier is commonly powered through the same coaxial cable carrying the received television signals. A power inserter inside the building places DC voltage onto the coax, which travels through the center conductor to the preamplifier.

RF attenuation and DC voltage drop are related to different electrical characteristics.

A cable might carry the RF signal adequately while having enough DC resistance to create excessive voltage drop when powering an outdoor device.

The voltage arriving at the preamplifier depends on the supply voltage, cable resistance, cable length, current consumed by the device, connectors, and other DC passing components in the path.

Excessive resistance can reduce the voltage available to the preamplifier and cause unreliable operation. Operating electronics outside their intended voltage conditions can also place unnecessary stress on the device.

For this reason, Channel Master does not select coaxial cable based solely on RF performance. Its current RG6 cables use an enhanced copper content center conductor and are specified for carrying DC power for amplifiers and powered antennas, including applications up to 24 volts DC over supported distances.

When troubleshooting repeated preamplifier or power related problems, the coaxial cable should therefore be evaluated as part of the DC power circuit as well as the RF signal path.

Yes. Coaxial cable is one of the most commonly overlooked components when troubleshooting an antenna system that previously worked reliably.

Consumers often assume the cable cannot be responsible because it has not been intentionally changed. However, a cable and its connectors are physical components that can deteriorate or develop problems over time.

For example, a staple or fastener that slightly damaged or compressed the cable during the original installation may not immediately cause a noticeable problem. Years of thermal expansion, contraction, vibration, moisture exposure, or movement can eventually make the damage more significant.

Outdoor connectors can loosen through repeated temperature cycles. A loose connector can compromise the RF shield and create a path for interference ingress or signal egress.

Moisture is another significant concern. A poorly sealed connector can allow water to migrate into the coaxial cable. Once moisture reaches the internal shielding, center conductor, or dielectric, corrosion and changes in the cable's electrical properties can progressively degrade performance.

Animals and rodents can also damage cable jackets, while sunlight can deteriorate cable that was not designed for long term UV exposure.

Therefore, when a previously reliable antenna system develops unexplained reception problems, the coaxial cable and every connector should be among the first components visually inspected, rather than automatically assuming that the antenna, amplifier, or television has failed.

Look for loose connectors, corrosion, damaged jackets, crushed cable, sharp bends, moisture, chew marks, deteriorated outdoor cable, and other physical damage.
